There are many forms of fiber optic transceiver used in fiber optic transmission. 1000BASE-LX/LH SFP, one of the typically used optical transceiver, is now widely used in optical community structures. Here are some common questions we might have when the use of Cisco 1000BASE-LX/LH SFP (GLC-LH-SM or GLC-LH-SMD) transceivers. And from the solutions, we would have a deeper knowledge of the use of these fiber optics.
Q1: Can 1000BASE-LX compatible with 100BASE-LX?
A1: 1000BASE-LX and 100BASE-FX are very exclusive standards. 1000BASE-LX SFP (GLC-LH-SMD) and 100BASE-LX SFP (GLC-FE-100LX) are 2 module types, one for GE and one for FE slots. The GLC-LH-SMD will no longer operate at 100Mbps. You will need to apply a 100Mb module to connect to some other device at 100Mb. Check optical transceiver compatibility with your system by means of reviewing the Cisco Fast Ethernet SFP module compatibility record and pick out the one it says is well matched.
Q2: What is the difference among LH and LX modules?
A2: Long Haul (LH) denotes longer distances while Long Wavelength (LX) denotes much less power which is obviously shorter distance. Before it was standardized 1000BASE-LX10 become essentially already in substantial use through many companies as a proprietary extension known as either 1000BASE-LX/LH or 1000BASE-LH.
Q3: Does 1000BASE-LX SFP work with 1000BASE-LH SFP? What does it infer if a module says like "Cisco 1000BASE-LX/LH SFP"?
A3: Yes, the 1000BASE-LX will paintings with the 1000BASE-LH. For example, Cisco 1000BASE-LX/LH SFP is either made for single mode (long distance) / multimode (brief distance). But this module may be used for each Single-mode and Multimode. The Cisco 1000BASE-LX/LH SFP, well suited with the IEEE 802.3z 1000BASE-LX widespread, operates on trendy single-mode fiber-optic hyperlink spans of up to 10 km and as much as 550 m on any multimode fibers. When used over legacy multimode fiber kind, the transmitter need to be coupled via a method conditioning patch cable.
Q4: What about Mode Conditioning Patch cords (MCP)?
A4: When choosing an optical transceiver, watch the transceiver’s consumer documentation for while a MCP ought to be used (see previous hyperlink for MCP records). They are occasionally required whilst your community’s set up optical cable is OM1 or OM2 rated multimode fiber (MMF). In quick, the MCP is an optical jumper that transitions the transmit fiber from a unmarried mode fiber (SMF) to a multimode fiber.
Q5: GLC-LH-SM SFP to 1000BASELX GBIC may not link over MMF?
A5: Cisco compatibility document says: "Some customers might be tempted to attach 1000BASE-LX/LH devices over brief reaches of MMF jumper cables with out MCP cables. There is a threat associated to this sort of nonstandard deployment, specifically when the jumper cable is an FDDI-grade or OM1 kind. In such case the power coupled at once into a sixty two.5-micron fiber may be as high as some dBm (typically 5 to 6 dBm), and if the jumper cable is short, the adjoining receiver might be saturated, causing excessive bit errors fee, and eventually irreversibly broken. We propose using MCP, however if the customer remains reluctant to the deployment of MCP, a five-dB attenuator for 1300nm need to be used and plugged on the transmitter of the optical module on every aspect of the hyperlink."
Q6: Does GLC-LH-SMD working with GLC-LH-SM?
If you want to realize extra, you may go to 10Gtekstore.
